Paneltronics Breaker 30 Amps A-Frame Magnetic Waterproof

Home > Paneltronics Breaker 30 Amps A-Frame Magnetic Waterproof
Paneltronics Breaker 30 Amps A-Frame Magnetic Waterproof
$23.87
Paneltronics
CWR-29833
Add
Panel Seal / Waterproof A Frame Magnetic Circuit Breakers

  • Branch AC or DC circuit breaker for Paneltronics electrical distribution panels
  • Meets all American Boat and Yacht Council (ABYC) Standards for non ignition protected circuit breakers
  • UL Recognized (UL 1077) for use in the U.S.A., and CSA Certified for use in Canada
  • Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)
  • Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)

Specifications

  • Handle Color Metal with Silicon rubber seal
  • Maximum Amperage 50 Amps
  • Maximum Voltage /AIC 32 VDC/ 2,500 Amps with no Back-up Fuse (ABYC E-11.10.1.5.5)
  • Rated Switch Cycles Rated Switch Cycles 10,000 actuations at rated current and voltage
  • Electrical Hardware Screw 10-32 x 3/8 pan combo head (P/N 197-188)
  • Mounting Hardware Hex nut 1/2-32 (supplied with circuit breaker)
  • Lockwasher 1/2 internal tooth (supplied with circuit breaker)
  • Optional Boot Black silicone rubber (P/N 048-015)
